Maksiwa Platinum Edgebander CBC.PCR - Corner Rounding

The NEW Maksiwa Platinum CBC.PCR Automatic Edgebander delivers industrial-grade performance with the highly requested corner rounding feature, making it the ideal solution for workshops and factories that demand superior finishing quality and productivity.

Despite its compact design, the CBC.PCR integrates a complete processing line, including pre-milling, trimming, corner rounding, glue scraping, and buffing, ensuring a premium, furniture-grade finish on every panel. Powered by a robust 8 HP motor and controlled via a user-friendly PLC touchscreen, this machine provides precision, consistency, and ease of operation.

The advanced XMELT glue pot system supports both EVA and PUR adhesives, featuring easy drainage and the C.A.S.S (Cleaning Agent Spraying System), which simplifies maintenance and reduces downtime. The CBC.PCR processes edge tapes from 0.4 to 3 mm and accommodates panel thicknesses from 8 to 50 mm, handling a wide range of professional applications with ease.

Key Features

• Corner rounding and pre-milling in a compact footprint

• Industrial-grade finishing with trimming, scraping, and buffing units

• XMELT glue pot system compatible with EVA & PUR adhesives

• C.A.S.S cleaning agent spraying system

• Conveyor chain feed system for optimal panel movement

• High-frequency motors with independent electronic converters

• Touchscreen PLC control for intuitive operation

• Compatible with Melamine, PVC, ABS, and PP edge tape

Additional Technical Information

• Edge Tape Thickness: 0.4 – 3 mm

• Panel Thickness Range: 8 – 50 mm

• Power Supply: 1 Phase – 220 V – 60 Hz

• Glue Pot Capacity: 1.5 kg | 3.3 lbs (Teflon coated)

• Automatic Feeding Speed: 18 ft/min (5.5 m/min)

• Net Weight: 1,411 lbs | 640 kg

• Sound Rating: 80 dB

Technical Specifications (SAE & Metric)

• Automatic Feeding Speed: 18 ft/min | 5.5 m/min

• Panel Thickness (Min / Max): 21/64” – 1 31/32” | 8 – 50 mm

• Maximum Pre-Milling Height: 1” | 30 mm

• Edgebanding Thickness: 0.0157” – 0.118” | 0.4 – 3 mm

• Glue Pot Capacity: 3.3 lbs | 1.5 kg

• Maximum Edgebanding Height: 2” | 51 mm

• Minimum Panel Width: 3” | 75 mm

• Minimum Panel Length: 7 7/8” | 200 mm

• Extendable Panel Support Rail Length: 103” | 2627 mm

• Extension Table Max Width: 54” | 1371 mm

• Dust Collector Port Size: 6” | 150 mm

• Minimum Dust Collection Requirement: 1236 CFM | 2100 m³/h

• Air Pressure Requirement: 14 SCFM @ 87 PSI | 0.7 MPa

• Edgebanding Coil Support Diameter: 59” | 1498 mm

• Recommended Glue Temperature: 356°F – 410°F | 180°C – 210°C

• Glue Type: Granulated Hot-Melt EVA / PUR

• Maximum Machine Dimensions (L x W x H):

  • 119” x 40 16/16” x 48 7/16” | 3026 x 1036 x 1230 mm

• Shipping Dimensions (L x W x H):

  • 111” x 30” x 57” | 2820 x 760 x 1448 mm

Motor & Electrical Specifications

• Electrical Requirement: 1 Phase – 220 V – 40 A – 60 Hz

• Conveyor Motor: 60 Hz – 1390 RPM – 0.66 kW

• Top & Bottom Trimmer HF Motors: 200 Hz – 12,000 RPM – 0.27 kW

• End & Corner Rounding Trimmer Motor: 200 Hz – 12,000 RPM – 0.27 kW

• Front & Rear Pre-Milling HF Motors:

  • 150 Hz – 9000 RPM – 0.75 / 0.25 kW

• Top Buffing Motor: 60 Hz – 1680 RPM – 0.11 kW

• Bottom Buffing Motor: 60 Hz – 1680 RPM – 0.11 kW

• Sound Rating: 80 dB
